ID GATE 6200
Flexible and Veratile Turnstile
ID GATE 62 is a flexible and versatile turnstile designed for access control in a wide range of environments, including office buildings, airports, public transportation systems, museums, stadiums, retail spaces, and universities.
It provides reliable and efficient access management for authorized personnel, enhancing overall site security.
By controlling entry to restricted areas, the turnstile helps maintain a safe and secure environment across all supported applications.
If you’re looking for a dependable and adaptable access control solution, ID GATE 6200 is the ideal choice.
ID GATE 62
Dimensions: 360 x 260 x 980 mm (L x W x H)
Passage Width: 550 mm (Arm length: 500 mm)
Material / Protection Class:
-
Stainless Steel 304 (IP44) – Indoor use
-
Stainless Steel 312 (IP65) – Outdoor use
Power Supply: AC 230V / 110V, 50/60 Hz
Power Consumption: 20W
Operating Voltage: 24V DC
Passage Frequency: Up to 35 people per minute
Emergency Mechanism: Automatic anti-panic folding arms
Communication Interface: Relay signal
Operating Temperature: -20 °C to +75 °C
Scope of Delivery
Stainless steel turnstile
Stainless steel barrier arms
Anchor bolts (M12) + nuts
Wired remote control (for testing only)
Cleaning kit
